Universal Strength Tester

Fabric Tensile Strength Tester with a variety of materials, the main speed of the tensile; tear, peel, fixed load, fixed elongation, elastic recovery rate, broken test test, the market widely used, the standard group Long-term supply of Fabric tensile strength machine, the price is reasonable and reasonable guarantee.

Fabric strength machine details

Product Description:

Mainly used for a variety of materials, weaving, non-woven timing, fixed speed stretching; torn, peeled, fixed load, fixed length, elastic recovery rate, broken, but also according to user requirements to provide friction and other tests Function instrument.

Standards compliant:

ASTM D5034. ASTM D 2261. ASTM D434. GB / T3923. GB / T3917. GB / T13772. FZ / T80007.1. ISO5081. DIN53859. DIN53858. BS3320. 4303. 2576. 2543

Fabric tensile strength machine Parameter Description:

1. the test mechanism: CRE test mechanism, high-speed sampling

2. control mode: computer control, liquid crystal display; print output

3. PC machine: record the whole process of testing, access to a powerful analysis, real-time display curve, breaking strength, elongation, yield stress, yield elongation, breaking off elongation, the initial modulus, the CV value A number of statistical indicators

4. measuring range: 100.0N, 2500N, 5000N, optional

5. the tensile speed: 2mm / min ~ 1200mm / min arbitrary

6. return speed: 2mm / min ~ 1000mm / min

7. timing stretch: 20s ± 3s, 30s ± 5s optional

8. the maximum set the number of stretching: 99 times

9. the average number of groups: 2 to 30 times (which can be calculated by the average, weft average)

10. elongation range: 200mm gauge when the elongation of up to 350%

11. gauge: 25 ~ 500mm between any regulation

12. Dimensions: 690mm × 480mm × 1270mm.

13. power: AC220V, 50HZ

14. Weight: about 130 kg
