Pilling & Snagging Tester

Bean Bag Snag Tester, to determine the snagging and picking resistance of knitted and woven fabrics by tumbling fabrics pillows containing a weighted bean bag within two separate test cylinders. Bean Bag Snag Tester complies with ASTM D5362. JIS L1058. etc. Bean Bag Snag Tester measures fabric by snagging resistance.

Application:

Bean Bag Snag Tester, to determine the snagging and picking resistance of knitted and woven fabrics by tumbling fabrics pillows containing a weighted bean bag within two separate test cylinders.

The bean bag snagging tester provides with eight pinned bars, rotating at 20RPM for 100 revolutions. Provided with predetermined electronic counter.

Standards:

ASTM D5362   JIS L1058

Specifications:

Rotation speed: 20r/min

Work stations: 2

Size of cylinder: Dia. 200mm

Pinned bars: 8 pcs / Cylinder

Needles: 9 pcs / Pinned bar

Bean bag: 450 g

Weight: 60 kg

Power: 220/110 V,50/60 Hz,3 A

Width:480 mm

Depth:380 mm

Height: 390 mm
