Taber abrasion resistance tester
Category：Abrasion Tester
Introduction
Range of application
TABER abrasion resistance tester and wear resistance tester can be replaced by wheel and weight,
which apply to the abrasion resistance performance test on fabric, cardboard, paint, leather, tile, glass and natural rubber,
method is simple and easy to operate,which has been widely used in various industry’s testing laboratory.
Abrasion tests, the material is standard wheel friction after a certain number of turns,
evaluate its abrasion resistance material weightlessness rate by calculation.
Abrasion wheel after pre grinding standard method, test results can reach very high consistency.
Core advantages
Simple operation, display real-time speed, the speed control can be achieved 30-75rpm adjustment,
wearing can be preset number of turns. Arm can match with balance weights, accurate weight balance abrasion arm,
to realize the ASTM standard which requires 125 g pressure requirements
Vacuuming mouth height is adjustable, and adapt to different thickness materials, efficient removal of debris, improve test accuracy
Brand motor, mute, low noise, smooth operation
Fabric Taber Abrasion Tester Specifications
| Abrasion table | Cambered surface -R100mm，Length-400mm |
| Test stroke | 76±2 mm |
| Abrasion velocity | 90±1 /min（double friction） |
| spinning speed | adjustable within the range of 30-75r/min (digital) |
| The sample surface diameter | 100mm |
| Sample table diameter | 113mm |
| setting range of Number of turns | 1-999999 |
| Air pressure | 250g |
| Tension adjusting weights | 340g (The force applied to the sample can be adjusted from 4.45 to 26.7 N) |
| Load weight | 150g (adjusted from 4.45 to 15.575N) |
| Tension of sample | 17.8N（adjustable） |
| Sample loading | 13.4N（adjustable） |
| Weight | Counterweight、250g、500g、750g、1000g |
| Wheel pressure range | 125g、250g、500g、750g、1000g、1250g |
| Vacuum arm height | Adjustable |
| power | 220V，50Hz |
| Size | 220mm×380mm×300mm |
| weight | 20kg |
